High performance color mixing beam angle 24° Color mixing Lens PMMA material smart control lamp diameter 25mm
Application: Spot light, Down light, Tracking light, Recessed lamp, Ceilling light
Lens material: PMMA all available
Lens features:
● It has excellent color mixing characteristics and is compatible with a variety of two-color chip
arrangements and some multi-color arrangement light sources.
● Lamp color drift is small after lens; Single color light source color drift is no more than 0.5SDCM after
lens, for example, light source fill in 2 SDCM, after lens no more than 2.5SDCM.
● The light angles at different view are clearly distinguishable.
● Soft and comfortable auxiliary lighting characteristics; no light exposure in the center of the spot, no
stray light after light be cut off, clean and comfortable.
● The interception of light is natural, lamp fit space better
Fit COB light source: Cree, Lumileds, Bridgelux, Citizen.....
| Specifications | | | | | |
| Part no | Light-emitting surface | FWHM | Size (mm) | Typ.eff | Material |
| WT-25@12-M15COBL4-C2 | ¢3/¢4mm COB | 15° | φ24.8×12.5 | 93% | PMMA |
| WT-25@12-M24-COBL4-C2 | ¢4mm COB | 24° | 88% | PC |
| WT-25@12-M36-COBL4-C2 | ¢4mm COB | 36° | 88% | PC |
